DX Eco-Touch Deck Oven

Combines the best of traditional baking techniques with modern engineering and unparalleled bake control.

For bakeries that need the latest and best in artisan-style bread baking!

Each deck has a single piece hearth stone and separate top/bottom temperature control.
Each deck has its own steam system, so you can achieve the amount of crust that you prefer.
Each deck is controlled by the user-friendly 'Eco-touch' touchscreen for easy programming and easy use.

Number of decks

1 - 5

Baking area, 2-wide decks

56 inch Wide x 32 inch Deep (1416 x 819 mm)

Baking area, 3-wide decks

74½ inch Wide x 32 inch Deep (1890 x 819 mm)

Compatibility

Worldwide

Certification

UL, CE

The DX Eco-touch gives you the artisan-style products that your customers crave!

For a full feature list, download the DX Eco-touch spec sheet (in 'Resources' below).

Independent controls for top and bottom heating elements to create the perfect balance of heat
Single piece, heavy sole plates for evenly distributed bottom heat perfect for traditional oven-bottom baked bread
Patented Cumulus Steam Generating System
Protection System ensures oven controls never overheat
Provides a gentle mellow bake each and every time

Rapid heat recovery rate
Simple damper facility for expelling air
Illuminated bake chamber using halogen bulbs with external access
Generous, thick slabs of rock wool insulation deliver exceptional heat retention
1 year parts/labor warranty

The 'Eco-touch' touchscreen controller is renowned for its easy programming and easy use - even by bakery novices!

Menu interface for fast, easy, and mistake free usage. Icons and illustrations are used for menu selection.
Up to 240 bake programs. Settings can be changed while the program is running.
'Favorites' menu accesses the most frequently used programs
7-day timer to start oven at selected times, ready for every shift. 4 events can be programmed for each day of the week.
'Help' function at top of every screen

'Sleep mode' returns each oven to a selected standby temperature to reduce energy consumption up to 66%
Auto-shutdown to prevent ovens from being left on by mistake
Diagnostics function to monitor performance and report status, while ovens are running
Voice prompts such as "Door Open", "Bake Over", etc can be activated as desired. (Standard alert tones and buzzers are also available)
All functions can be uploaded and downloaded via USB. This includes recipes, sounds and tones, logos, icons, images and software.

Spec Sheet
